Ventium — P5/P54C Replica Reference Documentation

Ventium is a high-fidelity replica of the Intel Pentium (P5/P54C, i586, non-MMX) microarchitecture, written as fully synthesizable SystemVerilog. It models the dual-issue, in-order, five-stage integer core — the U and V pipes, the fast-path single-cycle ALU, the carry-chain and shifter datapaths, the slow multi-cycle microsequencing FSM, the two-way set-associative L1 caches, the branch target buffer with its two-bit predictors, and the x87 floating-point stack — at a level of detail intended to reproduce the real part’s observable behaviour, instruction by instruction and cycle by cycle.

Correctness is established by differential verification against QEMU: the same program is executed on the Ventium RTL and on a QEMU reference, and the architectural state (register file, EFLAGS, memory, and — in cycle mode — the per-instruction retire trace, including U/V pipe assignment and pairing) is compared for bit-identity. Where the real silicon has documented quirks, the replica reproduces them faithfully: the Pentium FDIV flaw, the F00F (Erratum 81) lock-up, the FIST conversion erratum, and the AP-500 instruction-pairing rules are all modelled, gated behind explicit errata flags so a “clean” core and an “erratum-accurate” core can both be exercised. The FDIV flaw goes a step further: an optional, genuine radix-4 SRT divider reproduces it from first principles out of the reverse-engineered quotient-selection table — see The r4 SRT divider and the FDIV bug. The full set of sources behind the replica — Intel manuals and errata, the pipeline and timing literature, die-photo reverse engineering, and the emulators used as differential oracles — is cataloged in References.

The Instruction Catalog below is the heart of the reference: it walks every instruction category the integer and x87 cores decode, and for each instruction records what it computes, how it drives the pipeline datapath (fast path vs. slow microsequenced FSM, the AGU/ALU/shifter/FPU blocks it uses, and any forwarding or AGI interaction), which pipe — U or V — it may issue to and why, and an honest implementation status.
